Slurry distributor, system, and method for using same

(22) 21.10.2013

(43) 26.01.2018

(57) In order to help spread increasingly viscous gypsum slurries uniformly in the production of gypsum products, a slurry distributor includes a feed conduit and a distribution conduit in fluid communication therewith. The feed conduit includes an entry segment with a feed inlet and a feed entry outlet in fluid communication therewith and extending along a first feed flow axis. The feed conduit includes a shaped duct having a bulb portion in fluid communication with the feed entry outlet. The feed conduit includes a transition segment in fluid communication with the bulb portion and extending along a second feed flow axis in non-parallel relationship with the first feed flow axis. The bulb portion has an area of expansion with a cross-sectional flow area that is greater than a cross-sectional flow area of an adjacent area upstream from the area of expansion. The shaped duct has a convex interior surface in confronting relationship with the feed entry outlet of the entry segment to help promote the spread of the slurry moving therethrough.

(71) United States Gypsum Company (US)
