Steel silo modernizations and new pneumatic conveying systems for Aalborg Portland A/S
Claudius Peters Projects GmbH has won the contract to supply the basic & detail engineering, mechanical equipment, erection & supervision as well as the commissioning for upgrade of the dosing and transport of grey kiln dust and chalk dust at the cement plant of Aalborg Portland A/S, Denmark, part of the Cementir Group.
Chalk and grey kiln dust will together with calcined clay be used to substitute clinker for CO2 reduction.
Planning in an existing building is always a special challenge. For this purpose, Claudius Peters Projects created a 3D scan on site, furthermore a material test was carried out at the technical cen-ter, which led the customer to decide in favor of a C-Lever® flow meter system. Another important requirement from the customer was the implementation of an existing pressure vessel system as well as to ensure continuous operation of the cement mills during assembly.
In addition to the modernization of the chalk steel silo aeration, discharge & distribution system, Claudius Peters Projects GmbH will also supply:
4 pc. Well proven CPP X-200 Pumps with 2 integrated hopper dedusting filter
4 pc. Energy saving “Hybrid Rotary Blowers” with piping
1 pc. Set of Silo aeration panels with separate aeration blower
3 pc. CPP Flow Control Gates PCD
2 pc. Dosing rotary vales.
4 pc. Mass flow meters “C-Lever 50 direct (PSE)”
4 pc. Conveying lines with pneu. slide gates at end & complete supporting structure
1 pc. Dedusting filter cyclone with rotary feeder & discharge chute
The required electrical installation and integration into the plant control is carried out by the customer.
